The Case Model L Tractor Parts Catalog / manual seriall number 420,001 and up is a Reproduction of the original parts manual contains a complete list of parts for your tractor it is also an excellent source of information for reassembling your tractor. The parts catalog shows the tractor owner / operator;

Engine
Electrical System
Cooling System
Fuel System
Lubrication System
Transmission
Clutch
Drawbars
Steering and Front Axle
Brakes
Chassis
and more

The are parts grouped according to the location on the tractor.
Each group shows an "exploded view" which clearly illustrates each part in its correct relation to other parts in the illustration.
You need a parts catalog, it saves you time, money and helps you seem more informed when ordering parts

Also consider purchasing both the operators and service manual for your tractor, if available. The operator's manual adds all the basic information meant for the end user of the machine, while the service manual will lay out all the procedures for you.

A195

Case Model L Tractor Parts Catalog Manua l420k and up
